03 / DC Series · Direct Current
DC Load
Banks
Proving stored energy. DC-Series load banks discharge and test battery strings, UPS systems, telecom plant, traction supplies and battery energy storage — under precise constant-current or constant-power control, with full capacity logging.
Overview
Controlled discharge,
measured to the Ah.
A DC load bank draws a controlled current from a DC source so its true capacity and condition can be measured. For battery banks this means a timed discharge test that verifies real ampere-hour capacity against specification — the only reliable way to know a critical battery will hold up when mains is lost.
The DC-Series operates in constant-current, constant-power or constant-resistance modes across a wide voltage window, from 24 V telecom and switchgear-tripping batteries to 1000 V traction and BESS systems, with string monitoring and automatic test termination on a low-voltage threshold.
- Control Modes
- Constant current / power / resistance
- Voltage Window
- 24–1000 VDC (banded ranges)
- Metering
- V, A, kW, Ah, kWh with per-test logging
- Protection
- Reverse-polarity, over-current, low-voltage cut-off
- Formats
- Portable · wheeled · cabinet · containerised
Product range
DC Series
ratings.
A representative selection of the standard DC-Series range. Voltage banding, current rating, control mode and format are configurable — bespoke ratings are engineered to order.
| Model | Capacity | Voltage | Max Current | Mode | Format |
|---|---|---|---|---|---|
| DC-5 | 5 kW | 24–125 VDC | 200 A | CC/CP | Portable |
| DC-15 | 15 kW | 24–250 VDC | 500 A | CC/CP | Portable |
| DC-50 | 50 kW | 48–500 VDC | 600 A | CC/CP/CR | Wheeled |
| DC-150 | 150 kW | 110–750 VDC | 1000 A | CC/CP/CR | Cabinet |
| DC-300 | 300 kW | 110–1000 VDC | 1500 A | CC/CP/CR | Cabinet |
| DC-600 | 600 kW | 220–1000 VDC | 2000 A | CC/CP/CR | Containerised |
| DC-1000 | 1 MW | 500–1000 VDC | 2000 A | CC/CP/CR | Containerised |
Representative range — figures configurable to order.
Engineering
Built into every unit.
Multi-Mode Control
Constant current, constant power or constant resistance.
Wide Voltage Window
From 24 V telecom to 1000 V traction and BESS systems.
Capacity Logging
Ampere-hours and kWh measured and recorded per test.
Battery Protection
Reverse-polarity, over-current and low-voltage cut-off.
Robust Air-Cooled Elements
Heavy-duty resistive elements rated for long discharges.
Remote & Automated
PC / Modbus control with scheduled discharge sequences.
Applications
Where DC-Series
earns its place.
Wherever stored DC energy must be proven, characterised or commissioned.
Continue the range
Related families.
Specify your
DC-Series unit.
Tell us the system voltage, the test current or power and the capacity you need to prove, and we will return a full specification and quotation — typically within one working day.
